| ARC-8050T3U-16R |
|
Areca 3U 1 6Bay Rackmount Thunderbolt 3 Hardware RAID
|
|---|
 |
 |
|
|
| Hardware RAID Engine Dual-Core 1.2GHz RAID-on-Chip (ROC) w/ 2GB DDR3-1866 ECC Cache for maximum performance Supports RAID 0, 1, 1E, 3, 5, 6, 10, 30, 50, 60, Single Disk and JBOD |
|
|
| Scalability Maximize your capacity with Easy Expansion using the built-in MiniSAS HD (SFF-8644) Port to connect additional MiniSAS HD JBOD Expansion Enclosures Up to 512 drives total!!! |
|
|
 |
|||
|
Encryption
Host independent real-time controller-based hardware encryption that does not impact the performance Support 128bit and 256bit encryption keys using AES or password Support for Self-Encrypting Disks (SED) |
|||
|
|
|||
 |
|
|
|
|
| Specifications |
| Form Factor | : | 16 Bay 3U Rackmount 19-inch |
| Host Connection | : | Thunderbolt 3 (Dual-Port) |
| Drive Bay | : | 24x 3.5in/2.5in 12Gb/6Gb SAS/SATA drives |
| I/O Processor | : | Dual-Core 1.2GHz SAS ROC |
| On-Board Cache | : | 2GB DDR3-1866 |
| RAID Levels | : | 0, 1, 1E, 3, 5, 6, 10, 30, 50, 60, Single Disk, JBOD |
| Expansion Port | : | External MiniSAS HD (SFF-8644) |
| Cooling Fan | : | 2x Low-Noise / Hot-Swap |
| Power Supply | : | Dual Redundant 400W |
| DC Power | : | N/A |
| Dimensions (H x W x D) | : | 5.2 x 22.9 x 19 in (132.6 x 482 x 484 mm) - w/ Handles |
| Weight | : | 68.3 lbs (31 Kg) - Diskless |
| OS Support | : | MacOS X 10.2+ / Windows 8/10+ |
| Management | : | LCD / LAN Port (Out of Band Mangement) |
| Hardware Encryption | : | Controller Based 128/256-bit AES / Password |
| BBU Support | : | Yes (Optional) |
| Warranty | : | 3 Year |
|
|
||
|
|
 |
 |
